Dell
Dell Networking S3148P | 210-AIMP
Dell Networking S3148P | 210-AIMP
Couldn't load pickup availability
Dell Networking S3148P | 210-AIMP
Product Description
The S3100 switch offers a power-efficient and resilient Gigabit Ethernet (GbE) switching solution with integrated 10GbE uplinks for advanced Layer 3 distribution for offices and campus networks. The S3100 switch has high-performance capabilities and wire-speed performance utilizing a non-blocking architecture to easily handle unexpected traffic loads. The switches offer simple management and scalability via an 84 Gbps (full duplex) high-availability stacking architecture,that allows management from a single IP address.
Product Features
Modernize campus network architecturesLeverage familiar tools and practices
All S3100 switches feature Dell Networking OS9 for easier deployment and greater interoperability. One common command line interface (CLI) using a well-known command language means a faster learning curve for network administrators.
Deploy with confidence at any scale
S3100 switches help create performance assurance with a high data rate. Scale easily with built-in rear stacking ports. Switch stacks can be managed from a single screen using the highly available stacking architecture for high-density aggregation with seamless redundant availability.
Main Specifications
| Product Description | Dell Networking S3148P - switch - 48 ports - Managed - rack-mountable - Dell Smart Value |
| Device Type | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Bundled Services | 1 Year Dell ProSupport |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+ + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 30.8 W |
| Performance | Switching fabric bandwidth:260 Gbps ¦ Forwarding performance:193 Mpps |
| Capacity | MAC addresses:32000 ¦ IPv4 routes:1024 ¦ IPv6 routes:1024 ¦ IPv4 routes (dynamic):8160 ¦ IPv6 routes (dynamic):4096 ¦ Links per group:16 ¦ Priority queues per port:8 ¦ Layer 2 VLANs:4000 ¦ MSTP instances:64 ¦ VRF-lite instances:64 ¦ Host table entries (IPv4):40000 ¦ Host table entries (IPv6):8000 ¦ Multicast table entries (IPv4):8000 |
| MAC Address Table Size | 32K entries |
| Routing Protocol | VRRP,OSPFv2,IGMPv3,MSDP |
| Remote Management Protocol | SNMP 1,SNMP 2,RMON 1,RMON 2,RMON 3,RMON 9,SNMP 3 |
| Features | MDI/MDI-X switch,port mirroring |
| Compliant Standards | IEEE 802.3u,IEEE 802.3z,IEEE 802.1D,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.1p,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.1w,IEEE 802.1x,IEEE 802.3ae,IEEE 802.3ac,IEEE 802.1s,IEEE 802.1ab (LLDP) |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 43.4 cm x 40.7 cm x 4.35 cm |
| Weight | 6.9 kg |
| Manufacturer Selling Program | Dell Smart Value |
| Manufacturer Warranty | 1-year warranty |
Extended Specification
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - Managed - stackable |
| Bundled Services | 1 Year Dell ProSupport |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+ + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 30.8 W |
| Performance | Switching fabric bandwidth:260 Gbps Forwarding performance:193 Mpps |
| Capacity | MAC addresses:32000 IPv4 routes:1024 IPv6 routes:1024 IPv4 routes (dynamic):8160 IPv6 routes (dynamic):4096 Links per group:16 Priority queues per port:8 Layer 2 VLANs:4000 MSTP instances:64 VRF-lite instances:64 Host table entries (IPv4):40000 Host table entries (IPv6):8000 Multicast table entries (IPv4):8000 |
| MAC Address Table Size | 32K entries |
| Routing Protocol | VRRP,OSPFv2,IGMPv3,MSDP |
| Remote Management Protocol | SNMP 1,SNMP 2,RMON 1,RMON 2,RMON 3,RMON 9,SNMP 3 |
| Authentication Method | RADIUS |
| Features | MDI/MDI-X switch,port mirroring |
| Compliant Standards | IEEE 802.3u,IEEE 802.3z,IEEE 802.1D,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.1p,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.1w,IEEE 802.1x,IEEE 802.3ae,IEEE 802.3ac,IEEE 802.1s,IEEE 802.1ab (LLDP) |
| RAM | 2 GB |
| Expansion / Connectivity | |
|---|---|
| Interfaces | 48 x Gigabit LAN RJ-45 PoE+ - 30.8 W 2 x 10Gbit LAN SFP+ 2 x Gigabit LAN RJ-45/SFP 1 x USB Type A 1 x serial (RS-232) RJ-45 management 1 x 1000Base-T RJ-45 management |
| Power | |
|---|---|
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Power Provided | 1100 Watt |
| Miscellaneous | |
|---|---|
| Compliant Standards | EN 61000-3-2,EN 61000-3-3,EN 61000-4-4,EN 61000-4-2,EN 61000-4-3,EN 61000-4-6,EN 61000-4-5,FCC CFR47 Part 15 B,EN 60825-1,ISO 7779,VCCI V-3,EN 60825-2,ICES-003 issue 4 Class A,EN 55024-2:1998+A1:2001+A2:2003,EN 300 386 V1.4.1,AS/NZS CISPR22:2006 Class A,IEC/UL/CSA/EN 60950-1,EN 55022:2006+A1:2007 |
| Manufacturer Selling Program | Dell Smart Value |
| Dimensions &Weight | |
|---|---|
| Width | 43.4 cm |
| Depth | 40.7 cm |
| Height | 4.35 cm |
| Weight | 6.9 kg |
| Manufacturer Warranty | |
|---|---|
| Service &Support | - 1 year - response time:next business day |
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 65 °C |
