HPE Aruba Networking CX 10000-48Y6C Distributed Services Front-to-Back 6 Fans 2 PSU Switch Bdl
Manufacturer P/N and ITTL SKU: R8P13A#AC3
EAN: 190017537597
Product description
HPE Aruba Networking CX 10000-48Y6C Distributed Services Front-to-Back 6 Fans 2 PSU Switch Bdl provides 48 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 6 x 40/100 Gigabit QSFP+ / QSFP28. Review the management and performance details below and contact In Touch Telecoms for network design or quantity quotations.
Product features
- Ports: 48 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 6 x 40/100 Gigabit QSFP+ / QSFP28
- Performance: Switching capacity: 3.6 Tbps ¦ Latency: < 1.30 µs
- Remote Management Protocol: CLI, SNMP
Main specifications
| Product Description | HPE Aruba CX 10000-48Y6C - switch - 48 ports - Managed - rack-mountable |
|---|---|
| Device Type | Switch - 48 ports - L3 - Managed |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Subtype | 25 Gigabit Ethernet |
| Ports | 48 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 6 x 40/100 Gigabit QSFP+ / QSFP28 |
| Performance | Switching capacity: 3.6 Tbps ¦ Latency: < 1.30 µs |
| Capacity | IPv4 hosts: 120000 ¦ IPv6 hosts: 52000 ¦ IPv4 unicast direct routes: 131072 ¦ IPv6 unicast direct routes: 32732 ¦ IGMP groups: 4094 ¦ MLD groups: 4094 ¦ IPv4 routes (Multicast): 4094 ¦ IPv6 routes (Multicast): 4094 |
| MAC Address Table Size | 98K entries |
| Routing Protocol | Static IPv6 routing, static IPv4 routing, RIP-2, RIPng, OSPF, OSPFv3, BGP-4, ECMP, GRE, policy-based routing (PBR), Multiprotocol BGP |
| Remote Management Protocol | CLI, SNMP |
| Features | REST API interface |
| Power | (50 - 60 Hz) |
| Dimensions (WxDxH) | 43.82 cm x 51.1 cm x 4.44 cm |
| Weight | 9.75 kg |
| Manufacturer Warranty | 1-year warranty |
Extended specification
General
| Flash Memory | 64 MB |
|---|---|
| RAM | 32 GB |
| Device Type | Switch - 48 ports - L3 - Managed |
| Built-in Devices | 64 GB SSD |
| MAC Address Table Size | 98K entries |
| Subtype | 25 Gigabit Ethernet |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Ports | 48 x 1/10/25 Gigabit Ethernet SFP / SFP+ / SFP28 + 6 x 40/100 Gigabit QSFP+ / QSFP28 |
| Performance | Switching capacity: 3.6 Tbps / Latency: < 1.30 µs |
| Capacity | IPv4 hosts: 120000 / IPv6 hosts: 52000 / IPv4 unicast direct routes: 131072 / IPv6 unicast direct routes: 32732 / IGMP groups: 4094 / MLD groups: 4094 / IPv4 routes (Multicast): 4094 / IPv6 routes (Multicast): 4094 |
| Features | REST API interface |
| Routing Protocol | Static IPv6 routing, static IPv4 routing, RIP-2, RIPng, OSPF, OSPFv3, BGP-4, ECMP, GRE, policy-based routing (PBR), Multiprotocol BGP |
| Remote Management Protocol | CLI, SNMP |
Expansion / Connectivity
| Interfaces | 1 x serial RJ-45 / 1 x console (USB) / 1 x console (micro-USB) / 1 x LAN RJ-45 management |
|---|
Manufacturer Warranty
| Service & Support | Limited warranty - 1 year |
|---|
Miscellaneous
| Rack Mounting Kit | Optional |
|---|---|
| Included Accessories | 6 x fans |
Power
| Installed Qty | 2 |
|---|---|
| Max Supported Qty | 2 |
| Power Device | Internal power supply - hot-plug |
| Voltage Required | (50 - 60 Hz) |
| Power Provided | 550 watt |
Environmental Parameters
| Min Operating Temperature | 0 °C |
|---|---|
| Max Operating Temperature | 40 °C |
| Humidity Range Storage | 5 - 95% |
| Max Storage Temperature | 70 °C |
| Min Storage Temperature | -40 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
Dimensions & Weight
| Depth | 51.1 cm |
|---|---|
| Width | 43.82 cm |
| Height | 4.44 cm |
| Weight | 9.75 kg |
