HPE Aruba Networking CX 6100 24G Class4 PoE 4SFP+ 370W Switch
Manufacturer P/N and ITTL SKU: JL677A#ACC
EAN: 190017348520
Product description
HPE Aruba Networking CX 6100 24G Class4 PoE 4SFP+ 370W Switch provides 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+. Its 370 W PoE budget supports compatible powered devices. Review the management and performance details below and contact In Touch Telecoms for network design or quantity quotations.
Product features
- Ports: 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+
- Power Over Ethernet (PoE): PoE+
- PoE Budget: 370 W
- Performance: Switching capacity: 128 Gbps ¦ Throughput: 95.2 Mpps ¦ Latency (1 Gbps): 1.5 µs ¦ Latency (10 Gbps): 1.8 µs
Main specifications
| Product Description | HPE Aruba 6100 24G Class4 PoE 4SFP+ - switch - 28 ports - Managed - rack-mountable |
|---|---|
| Device Type | Switch - 28 ports - Managed - stackable |
| Enclosure Type | Side to side airflow rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 370 W |
| Performance | Switching capacity: 128 Gbps ¦ Throughput: 95.2 Mpps ¦ Latency (1 Gbps): 1.5 µs ¦ Latency (10 Gbps): 1.8 µs |
| Capacity | Switched virtual interfaces (SVIs): 16 ¦ ARP entries: 1024 ¦ IPv4 routes (Unicast): 512 ¦ IPv6 routes (Unicast): 512 ¦ IGMP groups: 512 ¦ MLD groups: 512 ¦ IPv4 ACL entries (ingress): 256 ¦ IPv6 ACL entries (ingress): 128 ¦ MAC ACL entries (ingress): 256 |
| MAC Address Table Size | 8192 entries |
| Routing Protocol | IGMPv2, IGMPv3 |
| Features | DNS client, VLAN support, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), LACP support, Energy Efficient Ethernet, flow control, UDP, TFTP support, ARP support, DHCP client, ICMP, SNTP support, BOOTP support, DiffServ support, EntityMIB, IPv6 addressing, IPv6 support, LLDP support, LLDP-MED, MIB, MLD snooping, NDP, NAC, port based access control, sFlow, SNMP support |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Power | AC 100-127/200-240 V (50/60 Hz) |
| Dimensions (WxDxH) | 44.2 cm x 26.82 cm x 4.39 cm |
| Weight | 4.19 kg |
| Localisation | English / United Kingdom |
| Manufacturer Warranty | Limited lifetime warranty |
Extended specification
General
| Flash Memory | 16 GB |
|---|---|
| Encryption Algorithm | SSL |
| Subtype | 10 Gigabit Ethernet |
| Routing Protocol | IGMPv2, IGMPv3 |
| PoE Budget | 370 W |
| Power Over Ethernet (PoE) | PoE+ |
| RAM | 4 GB DDR3 SDRAM |
| Device Type | Switch - 28 ports - Managed - stackable |
| MAC Address Table Size | 8192 entries |
| Ports | 24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ |
| Enclosure Type | Side to side airflow rack-mountable 1U |
| Capacity | Switched virtual interfaces (SVIs): 16 / ARP entries: 1024 / IPv4 routes (Unicast): 512 / IPv6 routes (Unicast): 512 / IGMP groups: 512 / MLD groups: 512 / IPv4 ACL entries (ingress): 256 / IPv6 ACL entries (ingress): 128 / MAC ACL entries (ingress): 256 |
| Processor | 1 x ARM A9: 1.016 GHz |
| Performance | Switching capacity: 128 Gbps / Throughput: 95.2 Mpps / Latency (1 Gbps): 1.5 µs / Latency (10 Gbps): 1.8 µs |
| Authentication Method | Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+, RADIUS |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Features | DNS client, VLAN support, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), LACP support, Energy Efficient Ethernet, flow control, UDP, TFTP support, ARP support, DHCP client, ICMP, SNTP support, BOOTP support, DiffServ support, EntityMIB, IPv6 addressing, IPv6 support, LLDP support, LLDP-MED, MIB, MLD snooping, NDP, NAC, port based access control, sFlow, SNMP support |
Expansion / Connectivity
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 / 4 x 1/10Gbit LAN SFP+ / 1 x USB-C console / 1 x USB Type A |
|---|
Manufacturer Warranty
| Service & Support | Limited warranty - lifetime |
|---|
Miscellaneous
| Localisation | English / United Kingdom |
|---|---|
| Compliant Standards | IEC/EN 60950-1, EN 60825, CAN/CSA C22.2 No. 60950 Second Edition, UL 60950-1 Second Edition, FCC Class A certified, VCCI Class A, EN 55022/CISPR 22 Class A, EN 60825-1:2007, IEC 60825-1:2007 Class 1, Laser Class 1, CISPR 24, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, IEC 61000-3-2, EN 61000-3-3, IEC 61000-3-3, RFC768, RFC1591, RFC783, RFC792, RFC2460, RFC2925, RFC1213, RFC1493, RFC2674 |
Power
| Power Consumption Operational | 22.9 Watt |
|---|---|
| Power Device | Internal power supply |
| Voltage Required | AC 100-127/200-240 V (50/60 Hz) |
| Power Provided | 500 Watt 2.3 A |
Environmental Parameters
| Min Operating Temperature | 0 °C |
|---|---|
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Humidity Range Storage | 15 - 90% (non-condensing) |
Dimensions & Weight
| Width | 44.2 cm |
|---|---|
| Height | 4.39 cm |
| Weight | 4.19 kg |
| Depth | 26.82 cm |
