SKU: JL808A#ACC
Barcode: 190017522661
In stock: 32
HPE
HPE Networking Instant On 1960 48G 2XGT 2SFP+ Switch | JL808A#ACC
HPE Partner
HPE Networking Instant On 1960 48G 2XGT 2SFP+ Switch | JL808A#ACC
Couldn't load pickup availability
Complete your setup
In Touch Telecoms โ HPE Business Partner
HPE Networking Instant On Switch 48p Gigabit 2p 10GBT 2p SFP+ 1960Manufacturer P/N: JL808A#ACCSmart-managed, stackable Gigabit Ethernet switch for business networks.Shipping weight: 6.26 kg. 48 Gigabit Ethernet RJ-45 access ports Two 10GBASE-T...
Full product details and specifications
HPE Networking Instant On Switch 48p Gigabit 2p 10GBT 2p SFP+ 1960
Manufacturer P/N: JL808A#ACC
Smart-managed, stackable Gigabit Ethernet switch for business networks.
Shipping weight: 6.26 kg.
- 48 Gigabit Ethernet RJ-45 access ports
- Two 10GBASE-T RJ-45 and two 10GbE SFP+ uplinks
- 176 Gbps switching capacity and 131 Mpps throughput
- Cloud management or local web interface, with stacking of up to four 1960 switches
- Non-PoE model, with rack mounting kit included
Full Product Specification ยท Request a built-to-specification option
Product description
The HPE Networking Instant On 1960 JL808A switch provides 48 Gigabit Ethernet ports and four 10GbE uplinks for growing business networks. Two copper 10GBASE-T ports and two SFP+ slots provide options for connecting servers, storage and other switches. This is the non-PoE model; it does not supply power to connected devices.
Manage the switch through the Instant On mobile app and cloud portal, or use its local web interface. Support for stacking up to four 1960 switches helps simplify management as your network expands. VLANs, access control lists and traffic prioritisation help organise and protect business traffic.
Need a network configured for your requirements? Use the built-to-specification enquiry form below to discuss switch quantities, compatible transceivers, cabling and support. This is a fixed-configuration switch; optional accessories and services are quoted separately and are not automatically included.
Product features
Robust security
Access control lists, denial-of-service protection and a Trusted Platform Module help protect the network. VLANs and port access controls help restrict access to authorised devices and users.
High performance
176 Gbps switching capacity and 131 Mpps throughput support demanding business traffic, with 10GbE uplinks for high-bandwidth connections.
Advanced manageability
Cloud management, a local web interface and support for protocols including HTTPS, SNMP and RMON provide flexible configuration and monitoring options. Available functions depend on the selected management mode.
Versatile connectivity
Connect devices through 48 Gigabit RJ-45 ports, with two additional 10GBASE-T ports and two SFP+ 10GbE uplink slots. Compatible SFP+ transceivers or direct-attach cables are optional.
Energy efficient
Energy Efficient Ethernet helps manage power use. TD lists operational power consumption of 80 W for this non-PoE model.
Main specifications
| Product | HPE Networking Instant On 1960 48G 2XGT 2SFP+ Switch |
|---|---|
| Manufacturer P/N | JL808A#ACC |
| EAN | 190017522661 |
| Device type | Smart-managed, stackable Gigabit Ethernet switch; L3 Lite |
| Ports | 48 ร 10/100/1000 RJ-45; 2 ร 10GBASE-T RJ-45; 2 ร 10GbE SFP+ |
| PoE | No |
| Switching capacity | 176 Gbps |
| Throughput | 131 Mpps |
| Form factor | Desktop or rack-mountable |
| Manufacturer warranty | Limited lifetime warranty |
ย
Extended specification
General
| Processor | 800 MHz |
|---|---|
| MAC address table | 16,000 entries |
| Jumbo frames | 9,216 bytes |
| Status indicators | Port status |
| Localisation | English / United Kingdom |
Performance and networking
| Latency | 100 Mbps: 4.4 ยตs; 1 Gbps: 2.2 ยตs; 10 Gbps: 1.1 ยตs |
|---|---|
| Routing table capacity | 32 IPv4 entries; 32 IPv6 entries |
| Routing and multicast | Static IPv4 routing; IGMP v1/v2/v3; MLD v1/v2 |
| Network features | VLAN, QoS, DSCP prioritisation, CoS, WRR, voice VLAN, port mirroring, STP/RSTP/MSTP, link aggregation, IGMP and MLD snooping |
| Security | ACL, DoS attack prevention, TPM, port security, DHCP snooping, IP source guard, ARP filtering and storm control |
| Authentication | RADIUS |
| Management protocols | HTTP, HTTPS, SNMP v1/v2c/v3, SCP, TFTP and RMON |
| Ethernet features | Auto-negotiation, flow control, auto MDI/MDI-X and IEEE 802.3az Energy Efficient Ethernet |
Connectivity and installation
| Gigabit access ports | 48 ร RJ-45 |
|---|---|
| 10GbE copper uplinks | 2 ร RJ-45 |
| 10GbE fibre uplinks | 2 ร SFP+ slots |
| Stacking | Up to four Instant On 1960 switches |
| Rack mounting kit | Included |
Power and environment
| Power supply | Internal AC power supply |
|---|---|
| Input | 100โ240 V AC, 50/60 Hz |
| Operational power consumption | 80 W (supplier specification) |
| Operating temperature | 0โ40 ยฐC |
| Storage temperature | โ40โ70 ยฐC |
| Operating and storage humidity | 15โ95%, non-condensing |
Dimensions and weight
| Dimensions (W ร D ร H) | 44.25 ร 35.05 ร 4.4 cm |
|---|---|
| Product weight | 4.4 kg |
| Shipping weight | 6.26 kg |
Manufacturer warranty and support
| Warranty | Limited lifetime warranty, subject to manufacturer terms |
|---|---|
| Live chat support | Lifetime, as listed by supplier |
| Phone support | 90 days from purchase, as listed by supplier |
Complete your network installation
Need RJ45 Ethernet cables for your installation? Add CAT6 ten-packs or CAT5e ten-packs in a choice of colours and lengths. Check the copper RJ45 port type, cable category and length required; cables for SFP/SFP+ fibre connections are different.
For multiple packs or a complete project, request a bulk quotation.
