HPE ProLiant DL360 Gen10 | DL360 G10 5218 MR416i-a NC BC Svr
HPE ProLiant DL360 Gen10 | DL360 G10 5218 MR416i-a NC BC Svr
Couldn't load pickup availability
HPE ProLiant DL360 Gen10 | DL360 G10 5218 MR416i-a NC BC Svr
Product Description
Does your data center need a secure,performance driven dense server that you can confidently deploy for virtualization,database,or high-performance computing? The HPE ProLiant DL360 Gen10 server delivers security,agility and flexibility without compromise. It supports the Intel Xeon Scalable processor with up to a 60% performance gain and 27% increase in cores,along with 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB with an increase in performance of up to 82%. With the added performance that HPE Persistent Memory,HPE NVDIMMs and 10 NVMe bring,the HPE ProLiant DL360 Gen10 means business. Deploy,update,monitor and maintain with ease by automating essential server life cycle management tasks with HPE OneView and HPE Integrated Lights Out 5 (iLO 5). Deploy this 2P secure platform for diverse workloads in space constrained environments.
Main Specifications
| Product Description | HPE ProLiant DL360 Gen10 Network Choice - rack-mountable - Xeon Gold 5218 2.3 GHz - 32 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Localisation | Region:Worldwide |
| Server Scalability | 2-way |
| Processor | 1 x Intel Xeon Gold 5218 / 2.3 GHz (3.9 GHz) (16-core) |
| Processor Socket | FCLGA3647 Socket |
| Processor Main Features | Hyper-Threading Technology,Intel Turbo Boost Technology 2 |
| Cache Memory | 22 MB L3 Cache |
| Cache Per Processor | 22 MB |
| RAM | 32 GB (installed) / 1.5 TB (max) - DDR4 SDRAM - Advanced ECC |
| Storage Controller | RAID (SAS 12Gb/s) (Broadcom MegaRAID MR416i-a) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Card Reader | Yes |
| Video Memory | 16 MB |
| Networking | 10 GigE |
| Power | (50/60 Hz) |
| Power Redundancy | Optional |
| Software Included | HPE Server UEFI |
| Dimensions (WxDxH) | 43.46 cm x 70.7 cm x 4.29 cm |
| Weight | 13.04 kg |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - parts and labour - 3 years - on-site - response time:next business day |
Associated Documents
- TD SYNNEX Product Data Sheet - HPE DL360 G10 5218 MR416i-a NC BC Svr(P56958-B21).pdf
- User Manual - HPE DL360 G10 5218 MR416i-a NC BC Svr(P56958-B21).pdf
Product Features
- Advanced performance with versatile compute
- HPE ProLiant DL360 Gen10 Server supports advanced technology leveraging the Intel Xeon Scalable processor with up to 28 cores and 3.0 TB of 2933 MT/s HPE DDR4 SmartMemory. HPE Persistent Memory works with DRAM to provide fast,high capacity,cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored,moved,and processed quickly. Achieve greater capacity with flexible drive configurations with up to 10 SFF and four LFF drives along with an option to support up to 10 NVMe PCIe SSDs delivering enhanced performance,capacity,and reliability to meet various customer segments and workload requirements at the right economics.
- Security innovations
- Modern features include Server Configuration Lock that ensures secure transit and locks server hardware configuration,iLO Security Dashboard helps detect and address possible security vulnerabilities and Workload Performance Advisor provides server tuning recommendations for better server performance. With Runtime Firmware Verification the server firmware is checked every 24 hours verifying validity and credibility of essential system firmware. Secure Recovery allows server firmware to rollback to the to last known good state or factory settings after detection of compromised code. Additional security options are available with Trusted Platform Module (TPM) to prevent unauthorized access to server and securely stores artifacts used to authenticate the server platforms while the Intrusion Detection Kit logs and alerts when the server hood is removed.
- High serviceability and deployment
- HPE ProLiant DL360 Gen10 Server comes with a complete set of services offered by HPE Pointnext,delivering confidence,reducing risk,and helping customers realize agility and stability. Advisory and Transformation Services professionals understand customer challenges and design an enhanced solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support. Services provided under Operational Services include - HPE Flexible Capacity,HPE Datacenter Care,HPE Infrastructure Automation,HPE Campus Care,HPE Proactive Services and multi-vendor coverage. HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
Extended Specification collapse
| General | |
|---|---|
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 8 |
| Localisation | Region:Worldwide |
| Processor / Chipset | |
|---|---|
| CPU | Intel Xeon Gold 5218 |
| Clock Speed | 2.3 GHz |
| Max Turbo Speed | 3.9 GHz |
| Number of Cores | 16-core |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology,Intel Turbo Boost Technology 2 |
| CPU Socket | FCLGA3647 Socket |
| Chipset Type | Intel C621 |
| Cache Memory | |
|---|---|
| Installed Size | L3 Cache - 22 MB |
| Cache Per Processor | 22 MB |
| RAM | |
|---|---|
| Installed Size | 32 GB / 1.5 TB (max) |
| Technology | DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed | 2666 MHz |
| Rated Memory Speed | 2933 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 24 (Total) / 23 (empty) |
| Features | Registered,slots 13 - 24 are available in two-processor configuration only,HPE SmartMemory |
| Configuration Features | 1 x 32 GB |
| RAM Supported | 3 TB Load-Reduced - ECC 1.5 TB registered - ECC 192 GB Non-Volatile - ECC |
| Hard Drive | |
|---|---|
| Type | No HDD |
| Storage Controller | |
|---|---|
| Type | 1 x RAID |
| Controller Interface Type | SAS 12Gb/s |
| Storage Controller Name | Broadcom MegaRAID MR416i-a |
| Buffer Size | 4 GB |
| Optical Storage | |
|---|---|
| Type | No optical drive |
| Card Reader | |
|---|---|
| Type | Card reader |
| Supported Flash Memory Cards | microSD |
| Monitor | |
|---|---|
| Monitor Type | None. |
| Graphics Controller | |
|---|---|
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Networking | |
|---|---|
| Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM57416 |
| Data Link Protocol | 10 Gigabit Ethernet |
| Remote Management Protocol | SNMP 3,IPMI 2.0,SMASH CLP |
| Remote Management Controller | Integrated Lights-Out 5 |
| Features | Wake on LAN (WoL),PXE support |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.1as,IEEE 802.3az |
| Expansion / Connectivity | |
|---|---|
| Bays | 1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots | 1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length,full-height 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile 1 (total) / 1 (free) x FlexibleLOM - three-quarter-length,full-height (low-profile) 1 (total) / 1 (free) x microSD Card (internal) 1 (total) / 1 (free) x PCIe x16 - full-height |
| Interfaces | 1 x HPE iLO - Type A (1 in front) 1 x HPE iLO - RJ-45 (1 rear) 5 x USB 3.0 (1 front,2 rear,2 internal) 1 x VGA (1 rear) 2 x LAN (10Gigabit Ethernet) (2 rear) |
| Miscellaneous | |
|---|---|
| Included Accessories | HPE Easy Install Rails,CPU standard heatsink,5 x standard fans |
| Compliant Standards | AES,FIPS 140-2,IPv6 Ready,PCI DSS,TLS v1.2,ASHRAE Class A4,ASHRAE Class A3,WEEE 2002/95/EC,ACPI 6.1 |
| Power | |
|---|---|
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 800 Watt |
| Operating System / Software | |
|---|---|
| Software | HPE Server UEFI |
| Environmental Standards | |
|---|---|
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 3.0 |
| Manufacturer Warranty | |
|---|---|
| Service &Support | Limited warranty - parts and labour - 3 years - on-site - response time:next business day |
| Dimensions &Weight | |
|---|---|
| Width | 43.46 cm |
| Depth | 70.7 cm |
| Height | 4.29 cm |
| Weight | 13.04 kg |
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
